| Type of battery pack | LiHD |
| Battery voltage | 18 V |
| Max sheet thickness for steel: 400 N/mm² | 1.6 mm / 0.0629 ” |
| Max sheet thickness for steel: 600 N/mm2 | 1.2 mm / 0.0472 ” |
| Max sheet thickness for steel: 800 N/mm2 | 0.7 mm / 0.0275 ” |
| Max sheet thickness for aluminium: 250 N/mm2 | 2 mm / 0.0787 ” |
| Strokes in idle | 1350 – 4840 rpm |
| Cutting speed | 7 m/min // 275 inch/min |
| Starting hole diameter | 27 mm / 1.0629 ” |
| Smallest curve radius | 15 mm / 0.5905 ” |
| Weight (including battery pack) | 1.9 kg |
| Vibration | |
| Cutting of sheets | 7.6 m/s² |
| Uncertainty of measurement K | 1.5 m/s² |
| Noise emission | |
| Sound pressure level | 74 dB(A) |
| Sound power level (LwA) | 85 dB(A) |
| Uncertainty of measurement K | 3 dB(A) |
