T822 Sutton Hand & Machine Straight Flute Bottoming Taps Metric HSS / Select

Brand

Item #

T822

MOQ

1

Categories

Cutting Tools, Hand & Machine Tap – Bottoming, Our Products, Taps & Dies

Dropdown

Sutton Tools HSS Taps are made in Australia for trusted quality. Suitable for general purpose use in hand or machine operations and depths up to 1 × Ø.

Tap Cut A variety of leads are available to suit various requirements
Square Shank For hard threading work in a variety of materials
HSS Made from High Speed Steel
Straight Flutes Suitable for through and blind holes

Description

Sutton Tools HSS Taps are made in Australia for trusted quality. Suitable for general purpose use in hand or machine operations and depths up to 1 × Ø.

Tap Cut A variety of leads are available to suit various requirements
Square Shank For hard threading work in a variety of materials
HSS Made from High Speed Steel
Straight Flutes Suitable for through and blind holes

Item #	Size	Pitch / TPI	O/A Length	Flute Length	Drill Ø
Metric
T822 0300	M3	x 0.5	48	11	2.5
T822 0400	M4	x 0.7	53	13	3.3
T822 0500	M5	x 0.8	58	16	4.2
T822 0600	M6	x 1.0	66	19	5.0
T822 0800	M8	x 1.25	72	22	6.8
T822 1000	M10	x 1.5	80	24	8.5
T822 1200	M12	x 1.75	89 2	9	10.2

Taps HSS | Sutton Tools

*** Full SUTTON TOOLS range available so if you don’t see it on our website just get in touch with us!

Description

Sutton Tools HSS Taps are made in Australia for trusted quality. Suitable for general purpose use in hand or machine operations and depths up to 1 × Ø.

Tap Cut A variety of leads are available to suit various requirements
Square Shank For hard threading work in a variety of materials
HSS Made from High Speed Steel
Straight Flutes Suitable for through and blind holes

Additional information

Dropdown	T822 0300 – M3 / TPI x 0.5, T822 0400 – M4 / TPI x 0.7, T822 0500 – M5 / TPI x 0.8, T822 0600 – M6 / TPI x 1.0, T822 0800 – M8 / TPI x 1.25, T822 1000 – M10 / TPI x 1.5, T822 1200 – M12 / TPI x 1.75
Brand	Sutton Tools
